HL-10CNC CNC Precision Sheet Circular Saw Machine for Composite Panels
Description
The machinery framework is in the heavy- -duty structure so that equipment enjoys stable operation.
The sawing foundation is in the lateral suspension structure; the glide device is arranged with double- -row roller type straight slide rail.
In the travelling of sawing foundation, the grinding gear, rack and servo motor are arranged to guaranteethe compatibility of sawing speed.
The pressing materials hood is in the overall design so that materials do not slide in the sawing.The sucking pipe is reserved; large power dust collector is arranged.
Except for the fioating rollers, all other contents on the working platform are made of chromium-plated steel plate in order to avoid scratch of materials.
Model: HL-10CNC automatic high-speed precision aluminum plate circular saw machine
▲ HL represents the model of Aluminum plate sawing machine in Heineda.
▲ 10 represents the size of the aluminum plate sawing machine, 10 can be sawd in width of 3300 mm.
▲ CNC represents this aluminum plate saw cutting machine for numerical control automatic model.
The suspended feeding clamp claw features as air pressure driving and clamping.
The driver of feeding mechanism is in the structure of servo motor + gear andrack.
The sawing foundation is elevated by hydraulic power; the ascending heightof sawingblade is setupaccording to the plate thickness.
Technical specifications and parameters
| Model |
HL-10CNC |
| Floating platform |
2 seats |
| Sawing length |
3300MM |
| Sawing width |
3300MM |
| Sawing height |
160/200 |
| Saw blade outer diameter |
550/630 |
| Clamping gripping |
8 groups |
| Rotational speed of Sawing blade |
3900 |
| Motor of sawing blade |
22/30 |
| Feeding servo motor |
3 |
| Travelling motor |
2(AC) |
FAQ
Q: Are you manufacturer ?
A:Yes, we have our own factory and we promise direct sales at a competitive price. Welcome to visit our factory at any time.
Q: Can I get a machine according to my own requirements?
A: Sure.We accept OEM and ODM.
Q: This is the first time I use this kind of machine, is it easy operate?
A: There are guide video that show how to use machine and english instruction book send to you with machine. If there is still have any question, we will provide free professinal guide for you until you could use machine well.
If you haven't found the machine you need, don't hesitate to contact us too. We will do best to give you the best suggestion.
